Setšoantšo sa No.: BA104S01-100
Ba104S01-100 ke sehlahisoa sa module sa 104-inch LCD se boletsoeng ke Boe Technology Group Co, Ltd. (Boe) u sebelisa theknoloji ea A-SCD-LCD. E na le thepa e potlakileng ea morao-rao, ha ho na khanya ea morao-rao ebile ha e ame. Ba104S01-100 e bonts'a qeto ea 800 (RGB) × 600 (SVGA) .1 e lokollotsoeng ka la 12 December × 5.9 (botenya) mm, kalafo e hlakileng e hlakile, boima ba sehlahisoa ke 288G Khutla Sehlahisoa sena se sebelisa mohloli oa lebone la 6S6P (holimo), bophelo ba mohloli oa leseli ke lihora tse 50K, ha ho koloi ea morao-rao. Ba104S01-100 Adpts Lvds (1 ch, 6/8-biy) Litefiso tsa eona tse tloaelehileng tsa ho phomola Fv ke 60hz. E sebetsa ka 70 ° C ho isa ho 70 ° C ho isa ho 80 ° C. Moetso ona o khothalletsoa tšebeliso ea indasteri le ea bongaka ka lebaka la mokokotlo oa eona oa Liipone, lihora tse fetang 50 000, li-pats tsa sebōpeho-leseling tse nyane, le likarolo tse ling.
| brand | BOE | Model name | BA104S01-100 |
| size | 10.4 inch | Screen type | a-Si TFT-LCD,LCD module |
| resolution ratio | 800(RGB)×600 [SVGA] 96PPI | Pixel configuration | RGB vertical bar |
| Display Area | 211.2×158.4 mm (H×V) | Surface treatment | Clear |
| Visual size | 215.0×162.0 mm (H×V) | Contrast Ratio | 800:1 (Typ.) (TM) |
| Brightness(cd/m²) | 500cd/m²(Typ.)or customized | Outline dimension | 236×176.9×5.9 mm (H×V×D) |
| Viewing Angle | 70/70/60/70 (Typ.)(CR≥10) | ||
| Signal interface | LVDS (1 ch, 6/8-bit) ,erminal, 20 pins | ||
| work environment | Storage temperature: -30 to 80 °C Operation Temperature: -20 to 70 °C |
Tse latelang ke mefuta le liparamente tse tšoanang
| brand | BOE | Model name | AV104X0M-N10 |
| size | 10.4 inch | Screen type | a-Si TFT-LCD,LCD module |
| resolution ratio | 1024(RGB)×768 (XGA) 123PPI | Pixel configuration | RGB vertical bar |
| Display Area | 210.4 × 157.8 (H×V) mm | Surface treatment | / |
| Visual size | 215.4 × 161.8 (H×V) mm | Contrast Ratio | 1100:1 (Typ.) (TM) |
| Brightness(cd/m²) | 600cd/m²(Typ.)or customized | Outline dimension | 230 × 180.2(H×V) |
| Viewing Angle | 85/85/85/85 (Typ.)(CR≥10) | ||
| Signal interface | LVDS (1 ch, 6/8-bit) ,erminal, 20 pins | ||
| work environment | Storage temperature: -40 to 95 °C Operation Temperature: -30 to 85 °C |
| brand | BOE | Model name | TDA104-001V02 |
| size | 10.4 inch | Screen type | a-Si TFT-LCD,LCD module |
| resolution ratio | 1024(RGB)×768 (XGA) 123PPI | Pixel configuration | RGB vertical bar |
| Display Area | 210.4 × 157.8 (H×V) mm | Surface treatment | / |
| Visual size | / | Contrast Ratio | 1000:1 (Typ.) (TM) |
| Brightness(cd/m²) | 900cd/m²(Typ.)or customized | Outline dimension | 235×173×10.5mm(H×V×D) |
| Viewing Angle | 85/85/85/85 (Typ.)(CR≥10) | ||
| Signal interface | LVDS (1 ch, 8-bit) ,erminal, 20 pins | ||
| work environment | Storage temperature: -55 to 85 °C Operation Temperature: -40 to 80 °C |
Li-tag tse chesang: Boe Ba104s01-100 4 500bits TCD Screen ea LCD bakeng sa ka ntle , LCD Module oa LCD, ponaletso e phahameng ea khanya.
