Min. Laela:1 Piece/Pieces
Setšoantšo sa No.: LQ150X1LG96
Mocheso o sebetsang oa lq150x1lg96 ke 0 ~ 65 ° C, mme mocheso wa polokelo o na -30 ~ 70 ° C ,3 ° C. E loketse likopo tsa indasteri, lintlha tsa sehlooho tsa sehlooho tsa kantle, lipapali. Tlhakolo ea bokaholimo ke matte Mabapi le mokokotlo, mohloli oa mofuta oa mofuta oa mofuta oa mofuta o na le nako ea bophelo ba 30k.
Sebaka sa Lq150x1LG96 Boholo ba sebaka sa li-lq150x1lg96 ke 304.128 × 228.096 (w × 203.5 (H) × 103.5 (H) × 103.5 (H) × 103.5 mm.
| brand | Sharp | Model name | LQ150X1LG96 |
| size | 15inch | Screen type | a-Si TFT-LCD,LCD module |
| resolution ratio | 1024(RGB)×768 [XGA] 85PPI | Pixel configuration | RGB vertical bar |
| Display Area | 304.128×228.096mm(H×V) | Surface treatment | Fog surface，Hard coating (3H) |
| Visual size | 307.2×231.1mm(H×V) | Contrast Ratio | 800:1 (Typ.) (TM) |
| Brightness(cd/m²) | 1050cd/m²(Typ.)or customized | Outline dimension | 326.5×253.5×10.1 mm(H×V×D) |
| Viewing Angle | 80/80/60/80 (Typ.)(CR≥10) | work environment | Storage temperature: -30 to 70 °C Operation Temperature: 0 to 65 °C |
| Signal interface | LVDS (1 ch, 6/8-bit),erminal,20 pins |
|
|
| supply voltage | 3.3V (Typ.) |
|
|
Litags tse chesang: 15inch pherp lq150x1lg96 tft lvds panera, skrineng sa libapali tse 55, skrineng Outdoor Lcd CHALL ea 2500 Ntsu , LCD Panel, LCD Module, pontso e phahameng ea khanya.
